Adder TS50-384 – 12 Micron Thermal Optic, 384x288 (50 Hz), 50mm Lens

The AGM Adder Thermal Optics integrate all advanced technology and electronics into the well-known 30 mm tube design of traditional rifle scopes. The Adder TS50-384 model combines a 50 mm germanium lens with an upgraded 384x288 pixel thermal detector and a 1024x768 OLED display, delivering one of the best images AGM has produced to date. The combination of the 12-micron sensor with the 50 mm lens also increases the base magnification of this particular model to 4X. Unlike smaller lenses with larger micron sensors, this combination allows predator hunters to start with a higher base magnification, eliminating the inevitable resolution degradation required in low-magnification units.

Additional improvements include an impressive battery life of up to 15 hours using two internal rechargeable 18650 batteries, 5 internal reticle options, and shot-activated video recording, ensuring that forgetting to press the record button is a thing of the past.

The entire Adder product family also includes a high-quality one-piece 30 mm quick-detach mount from American Defense Manufacturing. These mounts allow the optic to slide forward and backward to provide optimal eye relief for shooters using a wide variety of shooting platforms. Other features include, but are not limited to: 50 Hz refresh rate, IP67 waterproof rating, external power capability, built-in 64GB memory, 5 different reticle options, Wi-Fi compatibility with the AGM Connect app, multiple color palettes, audio recording, emergency power supply via CR123 battery, and of course, AGM’s transferable 5-year warranty.

• Thermal Resolution: 384×288
• High Sensitivity Detector: 12μm
• Fast 50 Hz Imaging
• High-Resolution OLED Display
• Digital Zoom 1x, 2x, 4x, 8x
• Built-in Video and Audio Recording
• Shot-Activated Recording (SAR)
• Wi-Fi Data Transmission
• Fast 64GB Built-in EMMC Storage
• Multiple Reticle Types and Colors
• Adjustable Color Palettes
• Standby Mode
• Waterproof and Shock Resistant
• Dual Power System
• Up to 15 Hours of Continuous Operation
• External Power Supply Capability
• 5-Year Warranty

Specifications

• Reticle: 5 types, 4 colors, on/off
• Zeroing Adjustment: Digital Control
• Zeroing Increment: 0.09 mil / 0.31 MOA
• Distance Measurement: Yes (Stadiametric)
• Scene Mode: Jungle, Recognition
• Picture-in-Picture (PIP) Mode: Yes
• Video Recording: Yes
• Defective Pixel Correction (DPC): Yes
• Uniformity Correction: Automatic, Manual, External Correction
• Digital Magnification: 4x - 32x
• Detector Type: 12μm, Uncooled, 50 Hz, < 35 mK (25°C, F# = 1.0)
• Standby Mode: Yes
• Resolution: 384 × 288
• Detection Range (6' Object): 2600 m/yd
• Snapshot: Yes
• Lens System: 50 mm; F/1.0
• Field of View (H × V): 5.4° × 4.0°
• Digital Zoom: 1×, 2×, 4×, 8×
• Diopter Adjustment Range: -5 to +5 dpt
• Eye Relief: ≥ 60 mm
• Display: 1024×768, 50 Hz, OLED
• Battery Type: Two Rechargeable 18650 Batteries (built-in) and one CR123 Battery
• Wi-Fi: Yes
• CVBS Output: Yes (via USB)
• Battery Life (Operating): Up to 15 hours
• Power Supply: 5 VDC/2 A, USB Type-C compatible with QC3.0
• Protection Rating: IP67
• Weight: 970 g (2.14 lb)
• Overall Dimensions: 420 × 78 × 82 mm (16.5 × 3.1 × 3.2 inches)
• Magnification: 4x
