MDR-X Battery swap
Install the battery and set the control-board jumper for the battery condition shown by Silverback.
Before you start
Safety, tools and revision
Safety. Disconnect the battery, wear eye protection and unload the replica. Follow local law; chronograph after any change that can affect energy.
Revision. 11.1 V normally needs no jumper; 7.4 V needs it as shown. Older/cold packs or a powerful spring may also need it.
Tools
- Eye protection
- Appropriate hand tools
- Chronograph where applicable
Primary source
Official Silverback tutorial
Procedure frames
Procedure
Step by step
1
Open the battery compartment
Follow the orientation in the official frame and video; do not force components.
2
Route the battery lead
Follow the orientation in the official frame and video; do not force components.
3
Set the PCB jumper only when required
Follow the orientation in the official frame and video; do not force components.
4
Close without pinching the lead
Before use, complete a safe function check and chronograph with the BB used.
Critical checks
- Battery disconnected and eye protection worn.
- No forced parts; official torque limits respected.
- Safe function check, chronograph and local compliance.
FAQ
Frequently asked questions
Which battery is recommended?
Silverback recommends 11.1 V.
Does it apply directly to V3?
Do not assume so: confirm V3 documentation and references before disassembly.
