Safety and limits. Wear eye protection. Connect air/battery only for controlled function and chronograph checks; disconnect both before service. Silverback recommends a maximum of 8 bar / 116 psi. Chronograph with the BB weight used and comply with local limits.

Chronograph-led procedure

1. Start point (00:14): use the factory value shown below. The correct dwell depends on regulator pressure.
2. Set energy first: load your game BBs, set hop-up minimum, and chronograph. The video begins at 5.5 bar / 80 psi.
3. Do not exceed 8 bar / 116 psi: if more energy is needed, select a less restricted nozzle rather than increasing pressure beyond the recommendation.
4. Empty the feed tube (02:22). Enter programming, select dwell with two trigger pulls, and validate using SINGLE → FULL → SINGLE.
5. Reduce progressively and test: after each decrease, test single and full-auto and chronograph. If function, energy, or consistency drops, increase dwell by 0.5 ms and re-test.

Official video

Procedure frames

FAQ

Verified pressure maximum.

The maximum recommended HPA pressure is 8 bar / 116 psi.

Verified setting.

The factory HPA dwell is 12 ms.
