♻️ Producto REACONDICIONADO (refurbished) oficial de AGM Global Vision. Unidad reacondicionada y verificada por el fabricante, con garantía oficial AGM. Disponible bajo pedido (on demand) — no en stock inmediato.

AGM Fuzion LRF Thermal Fusion Monocular

Available variants

• TM25-384: Fuzion LRF TM25-384 - Thermal Imaging Fusion and CMOS Monocular with Laser Rangefinder, 384x288 (50Hz), 25mm Lens
• TM35-384: Fuzion LRF TM35-384 - Thermal Fusion and CMOS Monocular with Laser Rangefinder, 384x288 (50Hz), 35mm Lens
• TM50-640: Fuzion LRF TM50-640 - Thermal Fusion Imaging and CMOS Monocular with Laser Rangefinder, 640x512 (50Hz), 50mm Lens

The AGM Fuzion LRF TM25-384 thermal and digital day/night vision monocular is one of the most technologically advanced and feature-packed optical devices in the world. The primary engine behind this monocular is its main thermal viewing channel, equipped with a highly sensitive 12-micron, 384x288 thermal detector. This AGM sensor ensures detection of human-sized heat signatures at distances of up to 0.8 miles (1250m). Unlike other thermal monoculars on the market, the Fuzion LRF is also equipped with a digital night vision channel, ideal for assisting in the recognition of targets detected by the thermal channel. The built-in 600m laser rangefinder takes the Fuzion LRF to another level, not to mention its 16GB of internal memory and Wi-Fi compatibility.

The Fuzion LRF also comes packed with numerous software enhancements and many features that have become standard within AGM’s thermal product range: highly sensitive thermal detector, 25mm germanium lens with 1.0 aperture, 1920x1080 ultra-low-light CMOS sensor, multiple viewing modes including image fusion and various color palettes, 2.5X base magnification with 8X digital zoom, picture-in-picture mode, integrated laser rangefinder, up to 5 hours of battery life with a removable rechargeable 18650 battery, USB Type-C port for external power supply capabilities, and IP67 waterproof rating. The package includes a long-range IR illuminator, wrist strap, charger, and of course, AGM’s transferable 5-year warranty.

• Dual-spectrum image fusion and object highlighting
• Enhanced detail and target recognition
• Selectable thermal viewing channel, visible light channel, or combined mode
• Highly sensitive 12 μm thermal detector, 35 mK NETD
• Fast 50 Hz imaging
• 1x, 2x, 4x, 8x digital zoom
• Digital image processing technology
• Ultra-low-light optical channel
• 1920x1080 optical resolution
• Eye-safe laser rangefinder
• 1024x768 resolution, 0.39-inch OLED display
• Video recording and snapshot capture, built-in 16 GB EMMC
• Wi-Fi hotspot
• Standby mode
• Up to 5 hours of continuous operation
• Waterproof
• 5-year warranty

Specifications

Palettes White Hot, Black Hot, Red Hot, Fusion, Visible, Image Fusion

Operating temperature -20°C to 55°C (-4°F to 131°F)

Dimensions (LxWxH) 158 × 61 × 57 mm (3.2 × 2.4 × 2.2 inches)

Distance measurement Yes (Laser rangefinder: up to 600 m, ±1 m accuracy)

Scene mode Jungle, Recognition

Hot spot tracking Yes

Observation distance 1250 m / yd

Detector type 12 μm VOx uncooled focal plane arrays

Spectral response band 8 μm to 14 μm

Optical image sensor 1/2" progressive scan CMOS, 1920 × 1080 at 25 fps

FFC (Flat Field Correction) Automatic, Manual, External Correction

Highest temperature spot tracking Yes

Standby mode Yes

Refresh rate 50 Hz

Aperture F1.0

Resolution 384 × 288

Laser wavelength 905 nm

Optical magnification 2.5x - 20x

Lens (focal length) Thermal lens focal length - 25 mm Optical module focal length - 22 mm

Power 5 VDC / 2 A, USB Type-C interface Supports external power supply

Field of view (H × V) 10.5° × 7.9°

Digital zoom 1x, 2x, 4x, 8x

Display 1024x768, 0.39-inch OLED screen, 50 Hz

Storage Built-in 16 GB EMMC

Video recording On-board video recording

Snapshot capture Yes

Battery type One rechargeable 18650 lithium battery (removable)

CVBS output Yes (via USB)

Battery operating time Up to 5 hours of continuous operation (@ 25°C, WiFi and CVBS off) Up to 3 hours of continuous operation (@ 25°C, WiFi and CVBS on)

Battery capacity display Yes

Weight 510 g (1.12 lb)

Protection level IP67 (Waterproof)
