Trigger PCB swap

Official video workshop · 3:10

MDR-X Trigger PCB swap

Replace the trigger PCB for the official Semi/Full or Semi-only configuration.

Before you start

Safety, tools and revision

Safety. Disconnect the battery, wear eye protection and unload the replica. Follow local law; chronograph after any change that can affect energy.
Revision. This is a legacy MDR-X V1/V2 trigger-board video. V3 documentation identifies a different trigger-board reference; use V3 documentation for V3 work.

Tools

  • Eye protection
  • Appropriate hand tools
  • Chronograph where applicable

Primary source

Official Silverback tutorial

Procedure frames

Procedure

Step by step

1

Remove power and open access

Follow the orientation in the official frame and video; do not force components.

Official video ↗

2

Disconnect the existing PCB

Follow the orientation in the official frame and video; do not force components.

Official video ↗

3

Fit the selected official PCB

Follow the orientation in the official frame and video; do not force components.

Official video ↗

4

Reassemble and function-check

Before use, complete a safe function check and chronograph with the BB used.

Official video ↗

Critical checks

  • Battery disconnected and eye protection worn.
  • No forced parts; official torque limits respected.
  • Safe function check, chronograph and local compliance.

FAQ

Frequently asked questions

Does every MDR-X ship with full auto?

The official description says single and full auto out of the box, except Germany.

Does it apply directly to V3?

Do not assume so: confirm V3 documentation and references before disassembly.
